Opis
Karakterisitke
- Wi-Fi i Bluetooth povezivost
- Praćenje potrošnje energije u stvarnom vremenu
- Pametno upravljanje sjenilima – radi s roletama, zavjesama, žaluzinama, tendama, prozorima, vratima, pokrovima za bazene i drugim dvosmjernim motorima te omogućuje potpunu kontrolu kretanja i pozicije
- Upravljanje kutom lamela za venecijanere
- Pametni rasporedi – otvaranje i zatvaranje prema vremenu, drugoj automatizaciji ili izlasku i zalasku sunca
- Pametne scene – povezivanje s drugim Shelly uređajima za složenije automatizacije
- Lokalno i cloud upravljanje
- Wi-Fi proširivač dometa i Bluetooth gateway
- Podrška za skriptiranje, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS, prilagođene certifikate i virtualne komponente
- Podrška za KNXnet/IP komunikaciju
Garancija (uključena u cijenu proizvoda): 3 godine u slučaju kvara uređaja kada se koristi u skladu i uvjetima opisanima u korisničkim uputama
Dodatne informacije:
| Quantity | Value |
|---|---|
| Physical | |
| Size (HxWxD): | 37x42x16 ±0.5 mm / 1.46×1.65×0.63 ±0.02 inch |
| Weight: | 30 g / 1.06 oz |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Conductor cross section: | 0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length: | 6 to 7 mm / 0.24 to 0.28 in |
| Mounting: | Wall box |
| Shell material: | Plastic |
| Shell color: | Black |
| Terminals color: | Black |
| Environmental | |
| Ambient working temperature: | -20°C to 40°C / -5°F to 105°F |
| Humidity: | 30% to 70% RH |
| Max. altitude: | 2000 m / 6562 ft |
| Electrical | |
| Power supply: | 110-240 V~ 50/60 Hz |
| Power consumption: | < 1.4 W |
| External protection: | Tripping characteristic B or C, 16A max. rated current, min. 6 kA interrupting rating, energy limiting class 3 |
| Output circuits ratings | |
| Max. switching voltage: | 240 V~ |
| Max. switching current AC: | 4 A for motors with compensated power factor (inductive loads) |
| Supported motor type: | Single-phase AC motors |
| Required limit switches: | Electronic or Mechanic |
| Sensors, meters | |
| Voltmeter (AC): | Yes |
| Ammeter (AC): | Yes |
| Internal-temperature sensor: | Yes |
| Radio | |
| Wi-Fi | |
| Protocol: | 802.11 b/g/n |
| RF band: | 2412 – 2472 МHz |
| Max. RF power: | < 20 dBm |
| Range: | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth | |
| Protocol: | 4.2 |
| RF band: | 2402 – 2480 MHz |
| Max. RF power: | < 4 dBm |
| Range: | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| Microcontroller unit | |
| CPU: | ESP-Shelly-C38F |
| Flash: | 8MB |
| Firmware capabilities | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | Yes |
| MQTT: | Yes |
